SKU：IENS，螺紋：1″12TPI RH轉M38
SKU：IYNS，螺紋：1 1/4″UNS 8TPI RH轉M38
SKU：ILNS，螺紋：1 1/4″8 TPI RH轉M38
SKU：IJNS，螺紋：1 1/8″12 TPI RH轉M38
SKU：IUNS，螺紋：1 1/8″12 TPI UNF RH轉M38
SKU: I7NS ,螺紋：1 1/8″8 TPI UN轉M38
SKU: IONS,螺紋：1 1/8″7 TPI BSW RH轉M38
SKU: IMNS，螺紋：1″10TPI BSF LH轉M38
SKU: ICNS, 螺紋：1″10TPI BSF RH轉M38
SKU: IXNS, 螺紋： 1″ 8TPI RH轉M38
SKU: IDNS, 螺紋：1″8TPI UNC RH轉M38
SKU: ITNS, 螺紋：1″8TPI Dual Threaded LH and RH轉M38
SKU: IHNS,螺紋：3/4″10TPI BSW RH轉M38
SKU: IBNS,螺紋：3/4″14TPI BSP LH轉M38
SKU: IANS,螺紋：3/4″14TPI BSP RH轉M38
SKU: I9NS,螺紋：3/4″16TPI RH with 6mm register轉M38
SKU: I6NS,螺紋：3/4″孔 轉M38
SKU: IRNS, 螺紋：1″8TPI孔 轉M38
SKU: ISNS, 螺紋：5/8 ″孔 轉M38
SKU: I8NS, 螺紋：7/8″12 NS LH轉M38
SKU: IVNS, 螺紋：TPI NF RH轉M38
SKU: IKNS, 螺紋：M18X2.5RH(Metric)轉M38
SKU: I3NS, 螺紋：M20x1.5RH(Metric)轉M38
SKU: I2NS, 螺紋：M20x2RH(Metric)轉M38
SKU: IINS, 螺紋：M24x3RH(Metric)轉M38
SKU: IWNS, 螺紋：M25x2RH(Metric)轉M38
SKU: IQNS, 螺紋：M30x3.5RH(Metric)轉M38
| SKU | Thread Diam. | Pitch | Thread Direction | Standard | Compatible Lathes | Set Screw |
|---|---|---|---|---|---|---|
| I2NS | M20 | 2 | RH | Tyme Cub | ||
| I3NS | M20 | 1.5 | RH |
Electra Beckum, Multico Sumaro |
||
| I6NS | 3/4″ | Plain Bore | M6 | |||
| I7NS | 1 1/8″ | 8TPI | UN(NOT UNC) | |||
| I8NS | 7/8″ | 12TPI | LH | NS | ||
| I9NS | 3/4″ | 16TPI | RH | (with 6mm register) | ||
| IANS | 3/4″ | 4TPI | RH | BSP | TL1000 (pre 1986) | |
| IBNS | 3/4″ | 4TPI | LH | BSP | TL1000 (pre 1986) | |
| ICNS | 1″ | 10TPI | RH | BSF | TL1000, Woodfast/Durden | |
| IDNS | 1″ | 8TPI | RH | UNC |
Delta, Rockwell, Golding, General, NOVA Comet (North America) and Mercury lathes |
|
| IENS | 1″ | 12TPI | RH | UNF |
Myford ML8 Turnstyler |
|
| IHNS | 3/4″ | 10TPI | RH | BSW |
Rockwell Homecraft |
|
| IINS | M24 | 3 | RH |
B-Line Arundel K600/K450 |
||
| IJNS | 1 1/8″ | 12TPI | RH | BSW |
Myford Mystro Masterlathe (New Zealand) |
|
| IKNS | M18 | 2.5 | RH | Elu DB 180 | ||
| ILNS | 1 1/4″ | 8TPI | RH |
NOVA Galaxi, NOVA Saturn, NOVA DVR 3000, NOVA XP, NOVA 1624 and 1624 II (North America) Laguna Revo |
M6 | |
| IMNS | 1″ | 10TPI | LH | BSF |
TL1000 Woodfast/Durden |
|
| INNS | Blank (Can be threaded up to 28mm) | |||||
| IONS | 1 1/8″ | 7TPI | RH | BSW | Morton | |
| IQNS | M30 | 3.5 | RH |
NOVA TL1500/3000/Comet (European & S. Hemisphere) Woodfast |
||
| IRNS | 1″ | 8TPI | RH | Jet 1221 Lathe | ||
| ISNS | 5/8″ | Plain Bore | Designed Specifically for Shopsmith Pro V and Power Pro Machines | M6 | ||
| ITNS | 1″ | 8TPI | Dual Threaded LH & RH | NOVA Mercury Mini Lathe | ||
| IUNS | 1 1/8″ | 12TPI | RH | UNF | Taiwanese lathes | |
| IVNS | 7/8″ | 14TPI | RH | NF | ||
| IYNS | 1 1/4″ | 8TPI | RH |
For lathes don’t have reverse turning ability |
||
| IWNS | M25 | 2 | RH | Tyme Avon (’83 on) and Classic Tanner SD165, Selbix Springwood, Sorby, Cotech | ||
| IXNS | 1″ | 8TPI | RH |
Designed specifically for the NOVA Comet II Midi Lathe, features lock for the reverse function. |
M | |
